1U
2U 3U 4U SLIDE RAIL |
|
.......................................................................................................................................................................................................................................................................................... |
|
|
600mm 2-layer 3-travel universal slide rail
* 獨特萬用設計，機箱寬度422~430mm，高度1234U，深度300~700mm，機箱兩側滑軌孔位不同者亦相容
* 3節3段式，最大延伸距離1100mm，每套單位為雙
* 採用超耐重雙層滑軌設計(65公斤)，如需安裝說明請參考此文件
* 包裝明細: 1雙/盒，NW.2.9KG,
GW.3.1KG, 0.09 CUFT (58cm x4.5cm x 9.5cm single box packed)
* 10盒/箱，NW.29KG,
GW.31KG, 0.96 CUFT |
|
|
|
1U
2U 3U 4U REAR MOUNTING KIT |
|
.......................................................................................................................................................................................................................................................................................... |
|
1234U-RMK
|
1234U rear mounting kit
* 1234U共用後端支架，支架深度300mm，每單位為1雙
* 獨特設計，兼容1234U高度的工業用電腦機箱，兼容機箱寬度428~430mm，機箱兩側孔位不同者亦相容
* 每單位零件包: 2個墊片‧4顆平頭M5螺絲
x 12mm‧2顆平頭M6螺絲
x 12mm |
|
|
|
POWER SUPPLY |
|
.......................................................................................................................................................................................................................................................................................... |
ATX0230FA
|
Enhance
brand
PS2 300W power supply with PFC
* AC交流電輸入電壓:
230V電壓
(台灣及美國及日本不適用)
* 標準內建溫控裝置
* Nekon與CE認證通過
* 機種尺寸及規格: D.140 x W.150 x H.86 /mm，one
two ball 80x25mm fan
*
出線定義圖 |
|
.......................................................................................................................................................................................................................................................................................... |
ATX0235FA
|
Enhance
brand
PS2 350W power supply with PFC
* AC交流電輸入電壓:
230V電壓
(台灣及美國及日本不適用)
* Nekon與CE認證通過
* 標準內建溫控裝置
* 機種尺寸及規格: D.140 x W.150 x H.86 /mm，one
two ball 80x25mm fan
*
出線定義圖 |
|
.......................................................................................................................................................................................................................................................................................... |
ATX0240FA
|
Enhance
brand
PS2 400W power supply with PFC
* AC交流電輸入電壓:
230V電壓
(台灣及美國及日本不適用)
* Nekon與CE認證通過
* 標準內建溫控裝置
* 機種尺寸及規格: D.140 x W.150 x H.86 /mm，one
two ball 80x25mm fan
*
出線定義圖 |
|
.......................................................................................................................................................................................................................................................................................... |
MA350~600-VA
|
PS2
350W/400W/500W/600W power supply
* AC交流電輸入電壓:
115V或230V兩者電壓可互調
(台灣適用)
* 機種尺寸及規格: D.140 x W.150 x H.86 /mm，one
Sunon 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
MA350~600-VA-A-PFC
|
PS2
350W/400W/500W/600W power supply with PFC
* AC交流電輸入電壓:
full range
115V~230V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86 /mm，one
Sunon 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
HG2-6300P
|
PS2 300W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
HG2-6400P
|
PS2 400W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan
* 主機板萬用電源接頭規格: 1組20+4pin(可拆裝),
1組ATX12V 4pin, 1組EPS12V 8pin |
|
.......................................................................................................................................................................................................................................................................................... |
HP2-6400P
|
PS2 400W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
HP2-6460P
|
PS2 460W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
HP2-6500P
|
PS2 500W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.140 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
SSM-6600P
|
PS2 600W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.160 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
PSL-6700P
|
PS2 700W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.220 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
PSL-6720P
|
PS2 720W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.220 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
PSL-6800P
|
PS2 800W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.220 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
PSL-6C00V
|
PS2 1200W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.220 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan
* 備註: 推薦適用於4U S420LB及S424LB chassis
*
出線定義圖 |
|
.......................................................................................................................................................................................................................................................................................... |
PSL-6850P
|
PS2 850W power
supply with PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.220 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan |
|
.......................................................................................................................................................................................................................................................................................... |
DPSM-6500F
|
PS2 DC -48V 500W
power supply
*
DC交流電輸入電壓:
-36V~-72V (全世界通訊適用)
* 機種尺寸及規格: D.160 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan
* 內建風扇轉速控制裝置 |
|
.......................................................................................................................................................................................................................................................................................... |
DPSM-6600F
|
PS2 DC -48V 600W
power supply
*
DC交流電輸入電壓:
-36V~-72V (全世界通訊適用)
* 機種尺寸及規格: D.160 x W.150 x H.86
/mm，one
two-ball-bearing 80x25mm fan
* 內建風扇轉速控制裝置 |
|
.......................................................................................................................................................................................................................................................................................... |
MRT-6300P
|
PS2 300W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.185 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRW-6400P
|
PS2 400W
mini redundant power supply
with PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.185 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRW-6420P
|
PS2 420W
mini redundant power supply
with PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.185 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MR3-6460P
|
PS2 460W
mini redundant power supply
with PFC
* AC交流電輸入電壓:
95V~264V (全世界適用)
* 機種尺寸及規格: D.254 x W.86
x H.150 /mm，3顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRG-6460P
|
PS2 460W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.200 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRG-6500P
|
PS2 500W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.200 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRM-6600P
|
PS2 600W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.254 x W.84
x H.150 /mm，4顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MX3-6600P
|
PS2 600W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
95V~264V (全世界適用)
* 機種尺寸及規格: D.254 x W.82
x H.150 /mm，3顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MX3-5700P
|
PS2 700W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
95V~264V (全世界適用)
* 機種尺寸及規格: D.265 x W.84
x H.150 /mm，3顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MX3-5750P
|
PS2 750W
mini redundant power supply with
PFC
* AC交流電輸入電壓:
100V~240V (全世界適用)
* 機種尺寸及規格: D.265 x W.84
x H.150 /mm，3顆4cm
ball bearing fans |
|
.......................................................................................................................................................................................................................................................................................... |
MRG-5800V4V
|
PS2 800W
mini redundant power supply with
PFC
*
AC交流電輸入電壓:
90V~264V (全世界適用)
* 機種尺寸及規格: D.200 x W.150 x H.86
/mm，4顆4cm
ball bearing fans
* 備註: 推薦適用於4U S420LB及S424LB chassis
*
出線定義圖 |
|
.......................................................................................................................................................................................................................................................................................... |
DMRW-6400F
|
PS2
DC -48V
400W mini
redundant power supply
* DC交流電輸入電壓:
-36V~-72V (全世界通訊適用)
* 機種尺寸及規格: D.185 x W.86
x H.150 /mm，4顆4cm
ball bearing fans |
|
